Description
| Technical Specifications – RG5F | |
|---|---|
| Print Heads | Ricoh Gen5 (7PL) / Ricoh Gen5 (5PL) |
| Print Heads Numbers | 2 to 12 Pcs (Optional as Required) |
| Color Options | CMYK / LC / LM / (White + Varnish Optional) |
| UV Lamp | UV LED Light |
| Print Resolution | 635 × 600 dpi | 635 × 900 dpi | 635 × 1200 dpi |
| Print Speed / Hour | High Speed (2 Row): 40 sqm/h | 45 sqm/h Production (2 Row): 28 sqm/h | 32 sqm/h Quality (2 Row): 21 sqm/h | 28 sqm/h |
| Media Thickness | 1–100 mm Max |
| Printing Size | 2440 × 1220 mm |
| Image Format | TIFF, JPEG, PostScript EPS, PDF |
| Acceptable Media | Glass, Acrylic, Wood, Ceramic, Metal, PVC, Plastic |
| RIP Software | PhotoPrint / Onyx |
| Power Supply | AC 220V, 50/60Hz, >30A |
| Communication | USB Port |
| Ink Tank Volume | 2 L |
| Environment Temperature | 20–28°C |
| Weight | 1762 Kg |
| Machine Size | 4660 × 2160 × 1480 mm |
| Outdoor Shelf Life | 2 Years (Using TOYO Ink) |
| Electricity | Power Consumption: 6.5 KW / 50A Power Supply: 220V AC, 50/60Hz |
| Warranty Time | One Year |
